產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 0 to 200 V
 ‧ Current: 0 to 17 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage: 0.035%, +145 mV
 ‧ Current: 0.2%, +25 mA
 ‧
 ‧ Ripple & Noise 20 Hz to 20 MHz
 ‧ Voltage rms: 22 mV
 ‧ Voltage Peak-to-Peak: 50 mV
 ‧ Current rms: 15 mA
 ‧
 ‧ Readback Accuracy at 25°C ±5°C
 ‧ Voltage: 0.08%, +80 mV
 ‧ Current: 0.36%, +15 mA

 應用範圍
